Goulds 1AS15 Aquavar Solo Constant Pressure Controller, 230 V, 1 Phase, 14 to 122 deg F, Domestic

Part #683

MFG #1AS15


Goulds 1AS15 Aquavar Solo Constant Pressure Controller, 230 V, 1 Phase, 14 to 122 deg F, Domestic

Part #683

MFG #1AS15

Sign In to See Your Price

Goulds 1AS15 Aquavar Solo Constant Pressure Controller, 230 V, 1 Phase, 14 to 122 deg F, Domestic

Part #683

MFG #1AS15

Item Features
  • Simple wiring and menu set-up.
  • Turns virtually any conventional system into a premium constant pressure system.
  • Fade-resistant LED display indicates system pressure, speed and current.
  • Error log displays last four faults and can be reset.
  • LED display clearly indicates actual system pressure, output frequency, current draw and error log.
  • Dual system set points for advanced system application.
  • Programmable output relay can be configured to run optional accessories such as a chlorinator, or link to a home monitoring system.
  • Rotary switch to set current limit to match motor service factor amps (SFA).
  • Choice of low or high sensitivity.
  • Choose a 5 or 20 psi pressure drop for restarts.
  • Set on or off depending on application.
  • Standard pressure sensor cable is 10 ft L.
  • Integrated output motor filter protects the motor from voltage spikes and limits electrical interference with devices such as portable telephones, radios, televisions and garage door openers.
  • 9.9 in W x 5.3 in D x 18.6 in H.
  • Pressure set point adjustable from 20 to 85 psi using the standard 100 psi transducer.
  • Input voltage single-phase, 230 V, 2-wire grounded system.
  • Output voltage variable voltage, variable frequency, single phase power to the 2-wire or 3-wire motor.
  • NEMA 3R enclosure rainproof, outdoor/indoor rated enclosure.
  • Speed/frequency 30 to 60 Hz only.
  • Motor Compatibility with 1/2 to 2 hp.
