Definite Purpose Contactors AC
White-Rodgers 90-245 90 Series Continuous-Duty Definite Purpose Contactor, 120 VAC V Coil, 30 A, 2 Poles
Part #
175745
MFG #
90-245
Email
Print
Copy Link
White-Rodgers 90-245 90 Series Continuous-Duty Definite Purpose Contactor, 120 VAC V Coil, 30 A, 2 Poles
Part #
175745
MFG #
90-245
Sign In to See Your Price
Sign In to Build Cart
Add to List
White-Rodgers 90-245 90 Series Continuous-Duty Definite Purpose Contactor, 120 VAC V Coil, 30 A, 2 Poles
Part #
175745
MFG #
90-245
Item Features
Attributes
Documents
Item Features
Low VA coil for cooler operation and increased life.
Quiet operation.
Universal style mounting bracket fits existing mounting holes.
Double break contacts ensure positive make and break.
Screw terminals or pressure connectors and double 1/4 in quick connects provided on all models for easy installation.
Contact block and carrier are high quality electrical-grade thermosetting resin insulating materia.
Attributes
Type
Continuous-Duty
Series
90 Series
Coil Voltage
120 VAC
Maximum Load Current
30 A
Number of Poles
2
Frequency Rating
50/60 Hz
Contact Rating
600 VAC
Terminal Type
Pressure Connector and Double 1/4 in Quick-Connect
Operating Temperature
-40 to 150 deg F
Mounting Type
Bracket
Material
Silver Alloy
Dimensions
2 in L x 2.313 in W x 2.61 in D
Documents
Specification Sheet
